含孔隙混凝土二维细观建模方法研究

陈青青; 张煜航; 张杰; 王志勇; 王志华

doi:10.21656/1000-0887.400058

含孔隙混凝土二维细观建模方法研究

doi: 10.21656/1000-0887.400058

太原理工大学机械与运载工程学院应用力学研究所;材料强度与结构冲击山西省重点实验室, 太原 030024

基金项目: 国家自然科学基金(11702186;11390361;11390362)

详细信息

作者简介:
陈青青（1993—），女，硕士生(E-mail: chenqingqing_5@163.com);王志勇（1982—），男，博士(通讯作者. E-mail: wangzhiyong@tyut.edu.cn).

中图分类号: TU37|TU528
计量
- 文章访问数: 1556
- HTML全文浏览量: 271
- PDF下载量: 408
- 被引次数: 0
出版历程
- 收稿日期: 2019-02-25
- 修回日期: 2019-04-18
- 刊出日期: 2020-02-01

Study on a 2D Mesoscopic Modeling Method for Concrete With Voids

Institute of Applied Mechanics, College of Mechanical and Vehicle Engineering; Shanxi Key Laboratory of Material Strength & Structural Impact, Taiyuan University of Technology, Taiyuan 030024, P.R.China

Funds: The National Natural Science Foundation of China(11702186;11390361;11390362)

摘要

摘要: 根据混凝土的细观组成和结构特点，对传统二维建模方法加以继承与改进，提出了一种高效的分步入侵判定算法.将孔隙直观地反映在模型中，建立了不同的含孔隙混凝土细观模型.对含圆形、椭圆形、多边形骨料与圆形、椭圆形孔隙的混凝土标准试件分别进行了建模研究，结果表明本文的算法具有较强适用性.同时，通过对不同面积率与多种形状骨料/孔隙混凝土的大量建模进一步验证了该算法的效率.模拟了混凝土试件在单轴压缩下的准静态力学性能，分析了混凝土内部孔隙对其裂纹扩展的主要路径、破坏模式以及宏观力学性能的显著影响.
- 混凝土 /
- 细观结构 /
- 孔隙 /
- 入侵判定 /
- 裂纹扩展
Abstract: According to the meso-structure of concrete, a high-efficiency stepwise overlap checking method was proposed based on traditional 2D modeling. Voids were introduced directly into the models and different concrete meso-structures were generated. The method involves various models containing circular, elliptical or polygonal aggregates and circular or elliptical voids. Meanwhile, several modeling examples based on different area fractions and different shapes of aggregates and voids were given to prove the computation efficiency of the proposed algorithm. At last, the mechanical behaviors of standard concrete specimens under uniaxial compression were simulated. The effects of internal voids on the main paths of crack propagation, concrete failure modes and macroscopic mechanical performances were analyzed.
- concrete /
- meso-structure /
- void /
- overlap checking /
- crack propagation
