High Precision Methods for Solving Multi-Body Systems With Close Loop Constraints
-
摘要: 含闭环约束多体系统的动力学方程是一组微分代数混合方程，它在数值求解过程中的主要难点有：①难以同时较高精度满足位移、速度、加速度约束方程，会随着误差的积累引起较大的违约；②经常存在冗余约束以及奇异构型问题，严重影响求解过程的数值性态和结果的准确性. 本文提出了一种可处理奇异构型闭环多体系统的数值求解方法，该方法摒弃了传统的约束独立性假设，在形成运动方程之前，对位置和速度进行修正，使其满足约束方程，而不是在每个积分步骤结束时纠正约束违约. 并且根据约束的几何特性可知，速度和加速度在超曲面约束法空间中的分量全部由约束决定. 通过列置换的QR分解得到约束法切空间的正交基向量，建立起系统广义速度与独立广义速度之间的关系，进而将微分代数混合方程转换为满足速度与加速度约束的纯微分方程(方程个数等于系统的广义坐标数)，这种方法可以与任何标准ODE求解器协作. 然后，将正交投影违约修正的方法应用到系统中，通过几次迭代有效地抑制系统位置和速度的违约量. 同时，依据虚功率等效原理，进一步揭示了Lagrange乘子在求解切断铰约束反力和约束反力矩中的重要物理意义. 本文所提方法可以动态识别独立约束，处理冗余约束和奇异构型问题，可高精度求解含闭环约束多体系统. 最后，通过几个数值算例验证了方法的有效性.Abstract: The dynamics equations for multi-body systems with closed-loop constraints are a set of differential algebraic mixed equations. The main difficulties in their numerical solution are as follow: it is difficult to satisfy the displacement, velocity and acceleration constraint equations with high precision at the same time, which will cause large defaults with the accumulation of errors; there are often redundant constraints and singular configuration problems, which seriously affect the numerical behavior of the solution process and the accuracy of the results. Herein, a numerical method for solving singular configuration closed-loop multibody systems was presented, without the traditional constraint independence assumption. The correction of position and velocity were done to satisfy the constraint equations before the motion equation formulation, rather than the correction of the constraint default at the end of each integration step. This method works with any standard ODE solver. According to the geometric characteristics of constraints, the components of velocity and acceleration in the hypersurface constraint space were all determined by constraints. The orthogonal basis vectors of the constrained tangent space were obtained through QR decomposition of the column permutation. The relationship between the generalized velocity of the system and the independent generalized velocity was established, and the default values of the generalized velocity and the generalized acceleration were filtered out in the dynamic calculation process, and the differential algebraic mixed equation was transformed into a pure differential equation satisfying the velocity and acceleration constraints (with the number of equations equal to the generalized coordinate number of the system). Then, the orthogonal projection default correction method was applied to the system, and the default magnitude of the system position and speed was effectively suppressed by several iterations. At the same time, according to the principle of virtual power equivalence, the physical significance of the Laplace multiplier in solving the constraint reaction torque of the cut hinge was further revealed. Numerical examples show that, the precision of displacement, velocity and acceleration constraints of the proposed method is higher than that of the traditional augmented method and the penalty function method. The proposed method can deal with redundant constraints and singular configuration problems, and can be programmed to solve multi-body systems with closed-loop constraints with high precision. The proposed method can identify the independent constraints dynamically and modify the motion equation accordingly. Numerical examples demonstrate the effectiveness of the proposed method.
-
图 2 约束生成的切空间和法空间
Figure 2. Tangent space St and normal space Sn resulting from constraints
图 6 求解铰的约束反力的拆解过程
Figure 6. The process of obtaining joint reaction forces in the derived tree-like system
图 9 滑块的违约量变化曲线(LM+Baumg.stab, ALF)
Figure 9. The curves of the slider's defaults(LM+Baumg.stab, ALF)
图 11 阻止铰点沿Y方向移动的约束反力
Figure 11. Constraint reactions to prevent joint point from moving along the Y direction
图 14 初值$\alpha_{1}=\pi / 2$时得到的C点x坐标的变化及其与解析解的差值
Figure 14. The x coordinates of point C and their differences with respect to the exact solutions with initial position $\alpha_{1}=\pi / 2$
图 15 初值$\alpha_{1}=\pi / 2$时得到的C点y坐标的变化及其与解析解的差值
Figure 15. The y coordinates of point C and their differences with respect to the exact solutions with initial position $\alpha_{1}=\pi / 2$
图 20 不同吊载作用下臂节3端部形心竖向位移及其振动频率的变化
Figure 20. Vertical displacements of the tip and their vibration frequencies for the 3rd boom under the actions of different loads
表 1 切断铰的约束
Table 1. Constraints of classical cut joints
revolute joint universal joint spherical joint prismatic joint cylinder joint rotational constraint α2=α3=0 α3=0 α1=α2=α3=0 α2=α3=0 translational constraint s1=s2=s3=0 s1=s2=s3=0 s1=s2=s3=0 s2=s3=0 s2=s3=0
下载: 导出CSV
表 2 不同分解方法的耗时(单位: s)
Table 2. Time costs of different decomposition methods (unit: s)
LU RREF pseudo inverse QR decomposition matrix dimension 4.57E-6 1.73E-3 6.24E-5 4.28E-6 20×20 1.12E-5 6.63E-3 2.10E-4 1.32E-5 40×40 2.73E-5 1.43E-2 8.45E-4 3.06E-5 60×60 2.54E-4 3.94E-2 1.49E-3 1.27E-4 100×100
下载: 导出CSV
表 3 Lagrange乘子表示的切断铰约束反力
Table 3. Reaction forces of classical cut-joints expressed in terms of Lagrange multipliers
revolute joint universal joint spherical joint prismatic joint cylinder joint m2 $\lambda_2 \boldsymbol{h}_2^2-\lambda_3 \boldsymbol{h}_2^3$ $\lambda_3\left(\boldsymbol{h}_2^2 \times \boldsymbol{h}_1^1\right)$ 0 $\lambda_2 \boldsymbol{h}_1^2-\lambda_1 \boldsymbol{h}_1^1-\lambda_3 \boldsymbol{h}_1^3$ $\lambda_2 \boldsymbol{h}_2^2-\lambda_3 \boldsymbol{h}_2^3$ f2 $\lambda_4 \boldsymbol{h}_1^1+\lambda_5 \boldsymbol{h}_1^2+\lambda_6 \boldsymbol{h}_1^3$ $\lambda_4 \boldsymbol{h}_1^1+\lambda_5 \boldsymbol{h}_1^2+\lambda_6 \boldsymbol{h}_1^3$ $\lambda_4 \boldsymbol{h}_1^1+\lambda_5 \boldsymbol{h}_1^2+\lambda_6 \boldsymbol{h}_1^3$ $\lambda_5 \boldsymbol{h}_1^2+\lambda_6 \boldsymbol{h}_1^3$ $\lambda_5 \boldsymbol{h}_1^2+\lambda_6 \boldsymbol{h}_1^3$
下载: 导出CSV
表 4 曲柄滑块机构的仿真参数
Table 4. Simulation parameters of the crank-slider mechanism
crankshaft length/m connecting rod length/m crankshaft mass/kg connecting rod mass/kg slider mass/kg 1 1 1 1 1
下载: 导出CSV
表 5 不同数值解法的仿真结果对比
Table 5. Validities of different numerical methods to simulate the 4-bar linkage
numerical solution method initial value >numerical solution method initial value >numerical solution method initial value $\alpha_{1}=\pi / 2$ α1=0 $\alpha_{1}=\pi / 2$ α1=0 $\alpha_{1}=\pi / 2$ α1=0 LM2 diverge diverge ALF+Coord.part diverge diverge MPI(GS) diverge diverge LM2+Baumg.stab diverge diverge MPI(SVD) diverge diverge MPI(GS)+Baumg.stab diverge diverge LM2+Coord.part diverge diverge MPI(SVD)+Baumg.stab diverge diverge MPI(GS)+Coord.part diverge diverge ALF diverge diverge MPI(SVD)+Coord.part converge converge this paper converge converge
下载: 导出CSV
-
