Free Vibration of Modified Axially Moving Timoshenko Beams
-
摘要: 考虑了剪切效应引起的转动惯量，应用物质坐标系下的Newton第二定理建立了修正的轴向移动Timoshenko梁模型. 求解了系统的固有频率，并分析了固有频率随梁长、梁高、轴向速度等参数变化的规律. 并将该文模型得到的结果与传统的轴向移动Euler-Bernoulli梁理论模型、轴向移动Rayleigh梁理论模型和轴向移动Timoshenko梁理论模型的结果进行对比. 结果表明：当轴向移动梁的长高比大于10时，四种模型得到的结果一致. 当长高比较小时，该文的结果与经典的轴向移动Timoshenko梁模型基本一致. 此外，剪切效应引起的转动惯量对高阶频率的影响更大. 因此，在轴向移动梁的动力学分析中应加以考虑剪切效应引起的转动惯量的影响.
-
关键词:
- 修正Timoshenko梁 /
- 剪切效应 /
- 转动惯量 /
- 自由振动 /
- 固有频率
Abstract: The rotational inertia caused by the shear effect was considered, and a modified axial motion Timoshenko beam model was established under Newton's 2nd law in the material coordinate system. The natural frequencies of the system were solved, and the laws of the natural frequencies changing with parameters such as the beam length, the beam height and the axial velocity, were analyzed. The results obtained by this model were compared with those by the traditional axially moving Euler-Bernoulli beam theoretical model, the axially moving Rayleigh beam theoretical model and the axially moving Timoshenko beam theoretical model. The results show that, when the length-to-height ratio of the axially moving beam is greater than 10, the results obtained by the 4 models are consistent. When the length-to-height ratio is relatively small, the present results are basically consistent with those by the classical axially moving Timoshenko beam model. In addition, the rotational inertia caused by the shear effect has a greater impact on higher-order frequencies. Therefore, the influence of the moment of inertia due to the shear effect shall be considered in the dynamic analysis of axially moving beams.-
Key words:
- modified Timoshenko beam /
- shear effect /
- moment of inertia /
- free vibration /
- natural frequency
-
图 2 不同梁长高比条件下四种轴向移动模型的一阶固有频率
注 为了解释图中的颜色，读者可以参考本文的电子网页版本，后同.
Figure 2. The 1st-order natural frequencies of 4 models with different beam length-height ratios
图 3 不同梁高度条件下四种轴向移动模型的一阶固有频率
Figure 3. The 1st-order natural frequencies of 4 models with different beam heights
图 4 不同轴向速度条件下四种轴向移动模型的一阶固有频率
Figure 4. The 1st-order natural frequencies of 4 models with different axial velocities
-
[1] Scheidl J, Vetyukov Y. Review and perspectives in applied mechanics of axially moving flexible structures[J]. Acta Mechanica, 2023, 234 (4): 1331-1364. doi: 10.1007/s00707-023-03514-5 [2] Zhu H, Zhu W D, Fan W. Dynamic modeling, simulation and experiment of power transmission belt drives: a systematic review[J]. Journal of Sound and Vibration, 2021, 491: 115759. doi: 10.1016/j.jsv.2020.115759 [3] 段应昌, 段壮志, 刘义, 等. 轴向运动梁动力学研究综述[J]. 兵器装备工程学报, 2021, 42 (6): 20-26.Duan Yingchang, Duan Zhuangzhi, Liu Yi, et al. Review of research on dynamics of axially moving beam[J]. Journal of Ordnance Equipment Engineering, 2021, 42 (6): 20-26. (in Chinese) [4] Liu M, Yao G. Nonlinear forced vibration and stability of an axially moving beam with a free internal hinge[J]. Nonlinear Dynamics, 2024, 112 (9): 6877-6896. doi: 10.1007/s11071-024-09447-5 [5] 马国亮, 陈立群. 轴向运动梁的横向随机响应[J]. 振动与冲击, 2014, 33 (9): 78-82.Ma Guoliang, Chen Liqun. Transverse random response of an axially moving beam[J]. Journal of Vibration and Shock, 2014, 33 (9): 78-82. (in Chinese) [6] Chang J R, Lin W J, Chen Y C, et al. Vibration and stability of an axially moving and spinning Rayleigh beam[J]. Journal of the Chinese Society of Mechanical Engineers, 2023, 44 (1): 1-10. [7] 王波, 蒋敏. 非线性轴向运动黏弹性Rayleigh梁受迫振动的微分求积法[J]. 机械设计与制造, 2020(4): 62-65.Wang Bo, Jiang Min. Forced vibration of nonlinear axially moving viscelastic Rayleigh beams with differential quadrature approach comparison[J]. Machinery Design & Manufacture, 2020(4): 62-65. (in Chinese) [8] Li Y, Ding J, Ding H, et al. Nonlinear parametric vibration and stability analysis of axially moving belt with non-homogeneous boundaries[J]. European Journal of Mechanics A: Solids, 2026, 115: 105837. doi: 10.1016/j.euromechsol.2025.105837 [9] Ding H, Tan X, Zhang G C, et al. Equilibrium bifurcation of high-speed axially moving Timoshenko beams[J]. Acta Mechanica, 2016, 227 (10): 3001-3014. doi: 10.1007/s00707-016-1677-3 [10] Ding H, Li Y, Chen L Q. Effects of rotary inertia on sub- and super-critical free vibration of an axially moving beam[J]. Meccanica, 2018, 53 (13): 3233-3249. doi: 10.1007/s11012-018-0891-6 [11] Ghayesh M H, Khadem S E. Rotary inertia and temperature effects on non-linear vibration, steady-state response and stability of an axially moving beam with time-dependent velocity[J]. International Journal of Mechanical Sciences, 2008, 50 (3): 389-404. doi: 10.1016/j.ijmecsci.2007.10.006 [12] Wang B. Effect of rotary inertia on stability of axially accelerating viscoelastic Rayleigh beams[J]. Applied Mathematics and Mechanics (English Edition), 2018, 39 (5): 717-732. doi: 10.1007/s10483-018-2322-6 [13] Elishakoff I, Hache F, Challamel N. Variational derivation of governing differential equations for truncated version of Bresse-Timoshenko beams[J]. Journal of Sound and Vibration, 2018, 435: 409-430. doi: 10.1016/j.jsv.2017.07.039 [14] 陈镕, 万春风, 薛松涛, 等. Timoshenko梁运动方程的修正及其影响[J]. 同济大学学报(自然科学版), 2005, 33 (6): 711-715.Chen Rong, Wan Chunfeng, Xue Songtao, et al. Modification of motion equation of Timoshenko beam and its effect[J]. Journal of Tongji University (Natural Science), 2005, 33 (6): 711-715. (in Chinese) [15] Liang J T, Wang Z, Zhang Y C, et al. Three-to-one internal resonance in supercritical modified axially moving Timoshenko beams[J]. Nonlinear Dynamics, 2025, 113 (17): 22507-22533. doi: 10.1007/s11071-025-11324-8 [16] Chen L Q, Yang X D. Steady-state response of axially moving viscoelastic beams with pulsating speed: comparison of two nonlinear models[J]. International Journal of Solids and Structures, 2005, 42 (1): 37-50. doi: 10.1016/j.ijsolstr.2004.07.003 -
