基于PSO-LSTM的负Poisson比材料力学性能预测与参数设计

胡雨涵; 韩芳; 颜芝

doi:10.21656/1000-0887.460118

基于PSO-LSTM的负Poisson比材料力学性能预测与参数设计

doi: 10.21656/1000-0887.460118

胡雨涵^1,,
韩芳^2, ,,
颜芝²

1.
武汉科技大学数学与系统科学学院, 武汉 430065
2.
武汉科技大学物理与力学学院, 武汉 430065

基金项目:

国家自然科学基金青年基金 51108358

详细信息

作者简介:
胡雨涵(1999—)，女，硕士生(E-mail: 1604032064@qq.com)

通讯作者:
韩芳(1980—)，女，副教授，博士(通信作者. E-mail: hanfang@wust.edu.cn)

中图分类号: TB34
计量
- 文章访问数: 142
- HTML全文浏览量: 46
- PDF下载量: 29
- 被引次数: 0
出版历程
- 收稿日期: 2025-06-09
- 修回日期: 2025-08-20
- 刊出日期: 2026-08-01

Mechanical Property Prediction and Parameter Design of Auxetic Materials Based on the PSO-LSTM

Hu Yuhan^1
,,
Han Fang^{2
, ,},
Yan Zhi²

1.
School of Mathematics and Systems Science, Wuhan University of Science and Technology, Wuhan 430065, P.R. China
2.
School of Physics and Mechanics, Wuhan University of Science and Technology, Wuhan 430065, P.R. China

摘要

摘要: 针对负Poisson比蜂窝材料力学性能预测与结构优化设计问题，提出一种融合粒子群优化(PSO)算法与长短期记忆(LSTM)网络的机器学习方法. 通过有限元仿真构建400组包含几何参数(直壁长度、胞元高度、壁厚、胞角)及其对应力学性能(能量吸收、弹性模量、Poisson比)的训练数据集，结合PSO对LSTM模型的超参数进行全局优化，建立多目标力学性能预测模型. 此外，构建基于PSO-LSTM的反向设计框架，通过目标力学性能驱动优化几何参数. 实验结果表明：优化后的PSO-LSTM模型对能量吸收、弹性模量和Poisson比的预测决定系数(R²)分别达到0.983 4，0.974 6和0.970 4，均方误差ε_ms稳定在0.001 2以下；反向设计所得模型的总能量吸收、弹性模量与Poisson比的相对误差分别为0.432%，1.05%和0.327%. 研究成果为负Poisson比材料的智能化设计与工程应用提供理论支持.
- 粒子群优化 /
- 长短期记忆网络 /
- 负Poisson比材料 /
- 几何参数设计
Abstract: To address the challenges of mechanical property prediction and structural optimization design for auxetic honeycomb materials, a machine learning approach integrating the particle swarm optimization (PSO) and the long short-term memory (LSTM) networks was proposed. A training dataset consisting of 400 groups of geometric parameters (including straight wall lengths, cell heights, wall thicknesses, and cell angles) and their corresponding mechanical properties (including energy absorption, Young's moduli, and Poisson's ratios) was constructed through finite element simulation. The PSO algorithm was employed to globally optimize the hyperparameters of the LSTM model, to establish a multi-objective mechanical property prediction model. Furthermore, an inverse design framework based on the PSO-LSTM was developed, enabling the optimization of geometric parameters driven by target mechanical properties. Experimental results show that, the optimized PSO-LSTM model achieves R² values of 0.983 4, 0.974 6, and 0.970 4 for energy absorption, Young's moduli, and Poisson's ratios, respectively, with mean squared errors (MSE) below 0.001 2. The relative errors of total energy absorption, Young's moduli, and Poisson's ratios for the model obtained through inverse design are 0.432%, 1.05%, and 0.327%, respectively. The proposed method provides theoretical support for the intelligent design and engineering application of auxetic materials.
- particle swarm optimization /
- long short-term memory network /
- auxetic material /
- geometric parameter design

HTML全文

图 1 算法原理图

Figure 1. The principle diagram of the PSO algorithm

下载: 全尺寸图片幻灯片

图 2 LSTM结构图

Figure 2. The structure diagram of the LSTM

下载: 全尺寸图片幻灯片

图 3 改进PSO-LSTM算法流程图

Figure 3. The flowchart of the improved PSO-LSTM algorithm

下载: 全尺寸图片幻灯片

图 4 内凹六边形蜂窝结构胞元的设计参数

Figure 4. Design parameters of the concave hexagonal honeycomb unit cell

下载: 全尺寸图片幻灯片

图 5 内凹六边形蜂窝的有限元模型

Figure 5. The finite element model of the concave hexagonal honeycomb

下载: 全尺寸图片幻灯片

图 6 PSO-LSTM模型对总能量吸收的预测结果

Figure 6. Prediction results of the PSO-LSTM model for total energy absorption

下载: 全尺寸图片幻灯片

图 7 PSO-LSTM模型对弹性模量的预测结果

Figure 7. Prediction results of the PSO-LSTM model for Young’s moduli

下载: 全尺寸图片幻灯片

图 8 PSO-LSTM模型对Poisson比的预测结果

Figure 8. Prediction results of the PSO-LSTM model for Poisson's ratios

下载: 全尺寸图片幻灯片

图 9 反向设计流程图

Figure 9. The flowchart of the inverse design process

下载: 全尺寸图片幻灯片

表 1 蜂窝结构参数的取值范围

Table 1. Ranges of honeycomb structural parameters

structural parameter	value range
θ/(°)	35~60
L/H	1~$\sqrt{3} $
t/mm	1~2

下载: 导出CSV

表 2 各模型对总能量吸收的预测结果

Table 2. Prediction results of various models for total energy absorption

	PSO-LSTM	LSTM	RF	SVM	XGBoost	ANN
R²	0.983 4	0.855 3	0.817 3	0.735 5	0.861 2	0.976 8
ε_ms	0.000 5	0.014 0	0.003 7	0.003 9	0.001 3	0.000 6

下载: 导出CSV

表 3 各模型对弹性模量的预测结果

Table 3. Prediction results of various models for Young's moduli

	PSO-LSTM	LSTM	RF	SVM	XGBoost	ANN
R²	0.974 6	0.764 5	0.717 0	0.616 6	0.846 1	0.890 9
ε_ms	0.000 7	0.003 3	0.004 6	0.006 6	0.002 0	0.001 5

下载: 导出CSV

表 4 各模型对Poisson比的预测结果

Table 4. Prediction results of various models for Poisson's ratios

	PSO-LSTM	LSTM	RF	SVM	XGBoost	ANN
R²	0.970 4	0.828 7	0.781 8	0.692 9	0.818 1	0.947 9
ε_ms	0.001 2	0.003 4	0.004 2	0.007 4	0.002 9	0.001 3

下载: 导出CSV

表 5 三种模型的反向设计结果

Table 5. Reverse design results of 3 models

	PSO-LSTM	GA-LSTM	GA-BPNN
E_{A_pred}	74.676	75.829	75.342
E_pred	22.232	21.972	22.243
ν_pred	-0.220 72	-0.225 44	-0.221 41

下载: 导出CSV

参考文献(18)

[1]	Gibson L J, Ashby M F, Schajer G S, et al. The mechanics of two-dimensional cellular materials[J]. Proceedings of the Royal Society of London A: Mathematical and Physical Sciences, 1982, 382(1782): 25-42. doi: 10.1098/rspa.1982.0087
[2]	Choi J B, Lakes R S. Non-linear properties of metallic cellular materials with a negative Poisson's ratio[J]. Journal of Materials Science, 1992, 27: 5375-5381. doi: 10.1007/BF02403846
[3]	Jin X, Wang Z, Ning J, et al. Dynamic response of sandwich structures with graded auxetic honeycomb cores under blast loading[J]. Composites Part B: Engineering, 2016, 106: 206-217. doi: 10.1016/j.compositesb.2016.09.037
[4]	魏高原. 拉胀材料研究的进展[J]. 材料导报, 2003, 17(1): 8-10. Wei Gaoyuan. Advances in research on auxetic materials[J]. Materials Review, 2003, 17(1): 8-10. (in Chinese)
[5]	Lakes R. Deformation mechanisms in negative Poisson's ratio materials: structural aspects[J]. Journal of Materials Science, 1991, 26: 2287-2292. doi: 10.1007/BF01130170
[6]	Grima J N, Gatt R, Alderson A, et al. On the potential of connected stars as auxetic systems[J]. Molecular Simulation, 2005, 31(13): 925-935. doi: 10.1080/08927020500401139
[7]	Grima J N, Evans K E. Auxetic behavior from rotating squares[J]. Journal of Materials Science Letters, 2000, 19: 1563-1565. doi: 10.1023/A:1006781224002
[8]	姚谦, 杨钊, 王昕, 等. 力学超结构设计方法研究进展[J]. 应用数学和力学, 2024, 45(8): 974-1000. Yao Qian, Yang Zhao, Wang Xin, et al. A review of design methods for mechanical metastructures[J]. Applied Mathematics and Mechanics, 2024, 45(8): 974-1000. (in Chinese)
[9]	Zhong S, Zhang K, Wang D, et al. Shedding light on "Black Box" machine learning models for predicting the reactivity of HO radicals toward organic compounds[J]. Chemical Engineering Journal, 2021, 405: 126627. doi: 10.1016/j.cej.2020.126627
[10]	刘溢凡, 马小敏, 王志勇, 等. 基于ANN的混凝土均匀化方法解析解[J]. 应用数学和力学, 2024, 45(5): 554-570. Liu Yifan, Ma Xiaomin, Wang Zhiyong, et al. Analytical solution of the concrete homogenization method based on the ANN[J]. Applied Mathematics and Mechanics, 2024, 45(5): 554-570. (in Chinese)
[11]	何明洋, 傅广, 靳尚坤, 等. 基于机器学习的多孔材料力学性能预测研究进展[J]. 复合材料学报, 2025, 42(8): 4311-4338. He Mingyang, Fu Guang, Jin Shangkun, et al. Research progress in prediction of mechanical properties of porous materials based on machine learning[J]. Acta Materiae Compositae Sinica, 2025, 42(8): 4311-4338. (in Chinese)
[12]	Tian J, Tang K, Chen X, et al. Machine learning-based prediction and inverse design of 2D metamaterial structures with tunable deformation-dependent Poisson's ratio[J]. Nanoscale, 2022, 14(35): 12677-12691. doi: 10.1039/D2NR02509D
[13]	Wang H, Xiao S H, Zhang C. Novel planar auxetic metamaterial perforated with orthogonally aligned oval-shaped holes and machine learning solutions[J]. Advanced Engineering Materials, 2021, 23(7): 2100102. doi: 10.1002/adem.202100102
[14]	马佩, 张君华, 权铁汉. 基于机器学习的负泊松比蜂窝的面内力学性能预测[J]. 复合材料学报, 2024, 41(7): 3803-3812. Ma Pei, Zhang Junhua, Quan Tiehan. Prediction of in-plane mechanical properties of auxetic honeycombs based on machine learning[J]. Acta Materiae Compositae Sinica, 2024, 41(7): 3803-3812. (in Chinese)
[15]	Chang Y, Wang H, Dong Q. Machine learning-based inverse design of auxetic metamaterial with zero Poisson's ratio[J]. Materials Today Communications, 2022, 30: 103186. doi: 10.1016/j.mtcomm.2022.103186
[16]	丁晨, 赵喜东, 亓昌, 等. 弧形双箭头蜂窝动态冲击平台应力神经网络预测方法[J]. 工程力学, 2025, 42(7): 265-272. Ding Chen, Zhao Xidong, Qi Chang, et al. Neural network prediction method for dynamic crushing plateau stress of circular double arrowed honeycomb[J]. Engineering Mechanics, 2025, 42(7): 265-272. (in Chinese)
[17]	刘振涛. 机器学习辅助超弹性多孔材料的结构设计[D]. 绵阳: 西南科技大学, 2023. Liu Zhentao. Structure design of hyperelastic porous materials with machine learning[D]. Mianyang: Southwest University of Science and Technology, 2023. (in Chinese)
[18]	周建新, 王鸿滔. 基于相似日理论和改进PSO-LSTM模型的风电短期出力预测[J]. 中国工程机械学报, 2024, 22(4): 447-451. Zhou Jianxin, Wang Hongtao. Short-term wind power prediction based on similar day theory and improved PSO-LSTM model[J]. Chinese Journal of Construction Machinery, 2024, 22(4): 447-451. (in Chinese))
