全过程下钻速度对地层裂缝宽度影响

赵世贵; 孔祥伟; 钟森

doi:10.21656/1000-0887.460178

全过程下钻速度对地层裂缝宽度影响

doi: 10.21656/1000-0887.460178

赵世贵^{1, 2,},
孔祥伟^{1, 2, ,},
钟森³

1.
长江大学石油工程学院, 武汉 430100
2.
油气钻完井技术国家工程研究中心(长江大学), 武汉 430100
3.
重庆渝浮能源发展有限公司, 重庆 400000

基金项目:

“十五五”新型油气勘探开发国家科技重大专项 SQ2025AAA120076

详细信息

作者简介:
赵世贵(1989—)，男，博士生(E-mail: zhao_shigui.stu@yangtzeu.edu.cn)

通讯作者:
孔祥伟(1982—)，男，博士，教授，博士生导师(通信作者. E-mail: 76922591@qq.com)

中图分类号: O39
计量
- 文章访问数: 135
- HTML全文浏览量: 51
- PDF下载量: 28
- 被引次数: 0
出版历程
- 收稿日期: 2025-09-20
- 修回日期: 2025-11-11
- 刊出日期: 2026-08-01

Effects of Entire Process Tripping-in Speeds on Formation Fracture Widths During the Entire Process

Zhao Shigui^{1, 2
,},
Kong Xiangwei^{1, 2
, ,},
Zhong Sen³

1.
School of Petroleum Engineering, Yangtze University, Wuhan 430100, P.R. China
2.
National Engineering Research Center for Oil & Gas Drilling and Completion Technology(Yangtze University), Wuhan 430100, P.R. China
3.
Chongqing Yufu Energy Development Co., Ltd., Chongqing 400000, P.R. China

摘要

摘要: 下钻速度通过影响井筒有效压力而引起地层裂缝宽度变化，造成井漏隐患. 结合下钻井深、钻具组合、地层岩石物理参数、钻井液性能，考虑下钻速度和钻井液可压缩系数等参数，建立了井筒压力瞬变与裂缝变形耦合作用的数学模型. 模型采用有限元-有限体积耦合方法进行求解，并利用四川盆地威远区块自X井龙马溪组硬脆性页岩地层数据验证了其可靠性. 结果表明：①下钻速度从0.5 m/s增加到2.0 m/s时，井筒压力从86.0 MPa增加到106.6 MPa，裂缝宽度从0.478 mm增加到0.881 mm. ②裂缝宽度随下钻井深、钻柱环空比的增加而增加. 下钻速度为0.5 m/s时，下钻井深从1 500 m增加到5 500 m，裂缝宽度从0.432 mm增加到0.478 mm；钻柱环空比从0.59增加到0.65，裂缝宽度从0.463 mm增加到0.487 mm. ③下钻速度从0增加到1.5 m/s，下钻井深为1 500 m时，裂缝宽度从0.4 mm增加到0.474 mm；下钻井深增加到5 500 m时，裂缝宽度从0.5 mm增加到0.624 mm；裂缝宽度随下钻速度增加而增加，下钻速度超过1.0 m/s后，增加趋势更加显著；且随着下钻井深增加，裂缝宽度的增加幅度越大. 本研究为优化下钻操作参数提供了理论依据，对预防钻井过程中的井漏事故具有重要指导意义.
- 下钻速度 /
- 裂缝宽度 /
- 井筒压力 /
- 流-固耦合
Abstract: The tripping-in speed affects the wellbore effective pressure, leading to changes in formation fracture widths and posing a risk of mud loss. The tripping-in speed and drilling fluid compressibility, along with the well depth, the bottom-hole assembly, the formation petrophysical parameters, and the drilling fluid properties were incorporated to build a mathematical model coupling wellbore pressure transients and fracture deformation. The model was solved with the finite element-finite volume coupling method and validated with data from the hard-brittle shale formation of the Longmaxi formation in the Zi X well of the Weiyuan Block in the Sichuan Basin. The results show that, i. when the tripping-in speed increase from 0.5 m/s to 2.0 m/s, the wellbore pressure will increase from 86.0 MPa to 106.6 MPa, while the fracture width will rise from 0.478 mm to 0.881 mm. ii. Bigger fracture widths go with greater tripping-in depths and higher drill string annular ratios. At a tripping-in speed of 0.5 m/s, when the tripping depth increases from 1 500 m to 5 500 m, the fracture width will rise from 0.432 mm to 0.478 mm; when the drill string annular ratio increases from 0.59 to 0.65, the fracture width will rise from 0.463 mm to 0.487 mm. iii. As the tripping-in speed increases from 0 to 1.5 m/s, at a tripping depth of 1 500 m, the fracture width will rise from 0.4 mm to 0.474 mm; at a tripping depth of 5 500 m, the fracture width will rise from 0.5 mm to 0.624 mm. Bigger fracture widths go with higher tripping-in speeds, and the rising trend will be more pronounced once the tripping-in speed exceeds 1.0 m/s; further, this rise becomes more pronounced with greater tripping depths. This study provides a theoretical basis for optimizing tripping-in operation parameters and offers an important guidance for preventing mud loss incidents during drilling.
- tripping-in speed /
- fracture width /
- wellbore pressure /
- fluid-solid coupling

HTML全文

图 1 井筒压力与裂缝宽度相互作用关系

Figure 1. The interaction between the wellbore pressure and the fracture width

下载: 全尺寸图片幻灯片

图 2 流-固耦合迭代技术路线

Figure 2. The technical workflow of fluid-solid coupling iteration

下载: 全尺寸图片幻灯片

图 3 下钻速度曲线

Figure 3. The tripping-in speed curves

下载: 全尺寸图片幻灯片

图 4 不同下钻速度下的井筒压力变化

Figure 4. Variations of the wellbore pressure under different tripping-in speeds

下载: 全尺寸图片幻灯片

图 5 不同下钻速度下的裂缝宽度变化

Figure 5. Variations of the fracture width under different tripping-in speeds

下载: 全尺寸图片幻灯片

图 6 不同下钻井深下的裂缝宽度变化

Figure 6. Variations of the fracture width at different tripping depths

下载: 全尺寸图片幻灯片

图 7 不同钻具组合与裂缝宽度变化

Figure 7. The variations of the fracture width with different BHA configurations

下载: 全尺寸图片幻灯片

图 8 全过程下钻速度与裂缝宽度变化

Figure 8. Variations of the fracture width during the entire tripping-in process

下载: 全尺寸图片幻灯片

表 1 井筒压力计算结果与现场实测结果对比

Table 1. Comparison of the wellbore pressure between calculated results and field measured results

tripping-in speed/(m/s)	measured result/MPa	calculated result/MPa	relative error/%
0.1	86.1	82.8	3.8
0.2	87.3	83.5	4.4
0.3	87.8	84.1	4.2
0.4	88.5	84.7	4.3

下载: 导出CSV

表 2 各钻具组合环空比

Table 2. Annular ratios of different bottom hole assemblies(BHA)

BHA	drill collar annular ratio	drill pipe annular ratio
1	0.76	0.59
2	0.76	0.65
3	0.81	0.68

下载: 导出CSV

参考文献(29)

[1]	雷少飞, 孙金声, 白英睿, 等. 裂缝封堵层形成机理及堵漏颗粒优选规则[J]. 石油勘探与开发, 2022, 49(3): 597-604. Lei Shaofei, Sun Jinsheng, Bai Yingrui, et al. Formation mechanisms of fracture plugging zone and optimization of plugging particles[J]. Petroleum Exploration and Development, 2022, 49(3): 597-604. (in Chinese)
[2]	邱正松, 刘均一, 周宝义, 等. 钻井液致密承压封堵裂缝机理与优化设计[J]. 石油学报, 2016, 37(增刊2): 137-143. Qiu Zhengsong, Liu Junyi, Zhou Baoyi, et al. Tight fracture-plugging mechanism and optimized design for plugging drilling fluid[J]. Acta Petrolei Sinica, 2016, 37(S2): 137-143. (in Chinese)
[3]	孙金声, 白英睿, 程荣超, 等. 裂缝性恶性井漏地层堵漏技术研究进展与展望[J]. 石油勘探与开发, 2021, 48(3): 630-638. Sun Jinsheng, Bai Yingrui, Cheng Rongchao, et al. Research progress and prospect of plugging technologies for fractured formation with severe lost circulation[J]. Petroleum Exploration and Development, 2021, 48(3): 630-638. (in Chinese)
[4]	舒刚, 孟英峰, 李红涛, 等. 裂缝内钻井液的漏失规律研究[J]. 石油钻采工艺, 2011, 33(6): 29-32. Shu Gang, Meng Yingfeng, Li Hongtao, et al. Research on leakage laws of drilling fluid in fracture reservoirs[J]. Oil Drilling & Production Technology, 2011, 33(6): 29-32. (in Chinese)
[5]	邸士莹, 程时清, 白文鹏, 等. 致密油藏动态裂缝扩展机理及应用[J]. 力学学报, 2021, 53(8): 2141-2155. Di Shiying, Cheng Shiqing, Bai Wenpeng, et al. Dynamic fracture propagation mechanism and application in tight oil reservoir[J]. Chinese Journal of Theoretical and Applied Mechanics, 2021, 53(8): 2141-2155. (in Chinese)
[6]	杨斌, 许成元, 张浩, 等. 深部破碎地层井壁失稳机理研究进展与攻关对策[J]. 石油学报, 2024, 45(5): 875-888. Yang Bin, Xu Chengyuan, Zhang Hao, et al. Research progress on mechanism of wellbore instability in deep fractured formations and related countermeasures[J]. Acta Petrolei Sinica, 2024, 45(5): 875-888. (in Chinese)
[7]	Mirabbasi S M, Ameri M J, Biglari F R, et al. Thermo-poroelastic wellbore strengthening modeling: an analytical approach based on fracture mechanics[J]. Journal of Petroleum Science and Engineering, 2020, 195: 107492. doi: 10.1016/j.petrol.2020.107492
[8]	Albattat R, Hoteit H. Modeling yield-power law drilling fluid loss in fractured formation[J]. Journal of Petroleum Science and Engineering, 2019, 182: 106273. doi: 10.1016/j.petrol.2019.106273
[9]	蔡文军, 丁建琦, 李中, 等. 基于地质力学数据的井下裂缝宽度智能预测方法研究与应用[J]. 科学技术与工程, 2024, 24(33): 14187-14194. Cai Wenjun, Ding Jianqi, Li Zhong, et al. Application of intelligent prediction method for underground fracture width based on geomechanical data[J]. Science Technology and Engineering, 2024, 24(33): 14187-14194. (in Chinese)
[10]	Dong Xiao, Meng Yingfeng, Zhao Xiangyang, et al. Liquid-liquid gravity displacement in a vertical fracture during drilling: experimental study and mathematical model[J]. Energy Exploration & Exploitation, 2020, 38(2): 533-554.
[11]	Zhu B Y, Tang H M, Yin S L, et al. Effect of fracture roughness on transport of suspended particles in fracture during drilling[J]. Journal of Petroleum Science and Engineering, 2021, 207: 109080. doi: 10.1016/j.petrol.2021.109080
[12]	曹玉玲, 何强胜, 刘闯. 考虑页岩塑性变形的水力裂缝与天然裂缝相交模拟研究[J]. 应用数学和力学, 2023, 44(6): 679-693. Cao Yuling, He Qiangsheng, Liu Chuang. Numerical simulation of hydraulic fractures intersecting natural fractures in shale with plastic deformation[J]. Applied Mathematics and Mechanics, 2023, 44(6): 679-693. (in Chinese)
[13]	张磊, 谢涛, 张羽臣, 等. 钻井过程中井筒裂缝动态扩展规律研究[J]. 非常规油气, 2021, 8(2): 114-119. Zhang Lei, Xie Tao, Zhang Yuchen, et al. Research on dynamic propagation law of wellbore fractures in drilling process[J]. Unconventional Oil & Gas, 2021, 8(2): 114-119. (in Chinese)
[14]	Dupriest F E. Fracture closure stress (FCS) and lost returns practices[C]//Society of Petroleum Engineers Journal, 92192 MS, 2005.
[15]	Crespo F E, Ahmed R M, Saasen A, et al. Surge-and-swab pressure predictions for yield-power-law drilling fluids[J]. Society of Petroleum Engineers Journal (Drilling & Completion), 2012, 27(4): 574-585.
[16]	张世锋, 李加宝, 汪海阁, 等. 泥(页)岩地层漏失诱导裂缝扩展机制及裂缝宽度预测[J]. 天然气工业, 2025, 45(4): 121-132. Zhang Shifeng, Li Jiabao, Wang Haige, et al. Mechanisms of lost circulation induced fracture propagation and fracture width prediction in shale reservoirs[J]. Natural Gas Industry, 2025, 45(4): 121-132. (in Chinese)
[17]	何新星, 李皋, 段慕白, 等. 地层裂缝动态变形对堵漏效果的影响研究[J]. 石油钻探技术, 2018, 46(4): 65-70. He Xinxing, Li Gao, Duan Mubai, et al. The influence of dynamic deformation of formation fractures on the plugging effect[J]. Petroleum Drilling Techniques, 2018, 46(4): 65-70. (in Chinese)
[18]	杜旭林, 苏彦春, 房茂军, 等. 致密砂岩气水两相流固耦合裂缝动态闭合分析半解析模型[J]. 天然气地球科学, 2024, 35(7): 1289-1303. Du Xulin, Su Yanchun, Fang Maojun, et al. A semi-analytical model coupled gas-water two-phase flow and geomechanics for dynamic closure analysis of fractures in tight sandstone[J]. Natural Gas Geoscience, 2024, 35(7): 1289-1303. (in Chinese)
[19]	彭浩, 李黔, 高佳佳, 等. 可变形天然裂缝动态宽度流-固耦合计算模型[J]. 西南石油大学学报(自然科学版), 2023, 45(2): 77-86. Peng Hao, Li Qian, Gao Jiajia, et al. Calculation model of hydro-mechanical coupling for dynamic width of deformable natural fracture[J]. Journal of Southwest Petroleum University (Science & Technology Edition), 2023, 45(2): 77-86. (in Chinese)
[20]	Verga F, Carugo C, Chelini V, et al. Detection and characterization of fractures in naturally fractured reservoirs[C]//Society of Petroleum Engineers Journal, 63266 MS, 2000.
[21]	王健, 徐加放, 赵密福, 等. 基于神经网络的钻井液漏失裂缝宽度预测研究[J]. 煤田地质与勘探, 2023, 51(9): 81-88. Wang Jian, Xu Jiafang, Zhao Mifu, et al. Prediction of crack width of drilling fluid leakage based on neural network[J]. Coal Geology & Exploration, 2023, 51(9): 81-88. (in Chinese)
[22]	彭浩, 李黔, 尹虎, 等. Lietard天然裂缝宽度预测模型新求解方法[J]. 石油钻探技术, 2016, 44(3): 72-76. Peng Hao, Li Qian, Yin Hu, et al. A new solution method for Lietard natural fracture width prediction model[J]. Petroleum Drilling Techniques, 2016, 44(3): 72-76. (in Chinese)
[23]	孔祥伟, 刘祚才, 靳彦欣. 川渝裂缝性地层自动压井环空多相压力波速特性研究[J]. 应用数学和力学, 2022, 43(12): 1370-1379. Kong Xiangwei, Liu Zuocai, Jin Yanxin. Study on multiphase pressure wave velocity characteristics of automatic kill annulus in Chuanyu fractured formation[J]. Applied Mathematics and Mechanics, 2022, 43(12): 1370-1379. (in Chinese)
[24]	金泰宇. 三维粗糙裂缝网络钻井液漏失流固耦合模型研究[J]. 石油钻探技术, 2024, 52(1): 69-77. Jin Taiyu. Study on three-dimensional fluid-solid coupling model of drilling fluid leakage in rough fracture network[J]. Petroleum Drilling Techniques, 2024, 52(1): 69-77. (in Chinese)
[25]	赵岩龙, 任传杰, 冯智, 等. 起下钻引发的环空瞬态波动压力计算方法[J]. 科学技术与工程, 2022, 22(13): 5198-5204. Zhao Yanlong, Ren Chuanjie, Feng Zhi, et al. Improved calculation of transient surge pressure in wellbore while tripping operations[J]. Science Technology and Engineering, 2022, 22(13): 5198-5204. (in Chinese)
[26]	Majidi R, Miska S Z, Yu M J, et al. Fracture ballooning in naturally fractured formations: mechanism and controlling factors[C]//Society of Petroleum Engineers Journal, 115526 MS, 2008.
[27]	Lavrov A, Tronvoll J. Mechanics of borehole ballooning in naturally fractured formations[C]//Society of Petroleum Engineers Journal, 93747 MS, 2005.
[28]	Lavrov A, Tronvoll J. Modeling mud loss in fractured formations[C]//Society of Petroleum Engineers Journal, 88700 MS, 2004.
[29]	Witherspoon P A, Wang J S, Iwai K, et al. Validity of cubic law for fluid flow in a deformable rock fracture[J]. Water Resources Research, 1980, 16(6): 1016-1024. doi: 10.1029/WR016i006p01016
