冲击荷载作用下水中悬浮隧道的位移响应

张嫄; 董满生; 唐飞

doi:10.3879/j.issn.1000-0887.2016.05.004

冲击荷载作用下水中悬浮隧道的位移响应

doi: 10.3879/j.issn.1000-0887.2016.05.004

张嫄¹,
董满生^1,2,
唐飞¹

¹合肥工业大学交通运输工程学院, 合肥 230009;²招商局重庆交通科研设计院有限公司, 重庆 400067

基金项目: 交通运输部建设科技项目(2013318740050)；中国博士后科学基金(20110490833)；国家山区公路工程技术研究中心项目(GSGZJ-2014-05)

详细信息

作者简介:
张嫄（1991—），女，硕士生（E-mail: matcha74@sina.cn）；董满生（1973—），男，副教授，博士，硕士生导师（通讯作者.E-mail: dongms@hfut.edu.cn).

中图分类号: U495.5
计量
- 文章访问数: 1137
- HTML全文浏览量: 147
- PDF下载量: 679
- 被引次数: 0
出版历程
- 收稿日期: 2015-09-07
- 修回日期: 2016-02-05
- 刊出日期: 2016-05-15

Displacement Responses of Submerged Floating Tunnels Under Impact Loads

¹School of Transportation Engineering, Hefei University of Technology, Hefei 230009, P.R.China;²China Merchants Chongqing Communications Technology Research & Design Institute Co., Ltd., Chongqing 400067, P.R.China

Funds: China Postdoctoral Science Foundation(20110490833)

摘要

摘要: 建立冲击荷载作用下悬浮隧道的动力学模型，将悬浮隧道简化为等距离弹性支撑梁，通过Galerkin(伽辽金)法求解悬浮隧道的振动位移方程，数值模拟悬浮隧道跨中时程响应，分析张力腿竖向刚度、冲击物质量、冲击速度对悬浮隧道跨中位移的影响.结果表明：冲击荷载作用下，张力腿竖向刚度对悬浮隧道位移响应的影响显著，但具有极限性.其次，冲击物质量和冲击速度也会显著影响悬浮隧道的跨中振动位移.研究结论为未来悬浮隧道的研究和建设提供重要的理论参考.
- 水中悬浮隧道 /
- 冲击荷载 /
- 位移响应 /
- 参数设计 /
- 数值模拟
Abstract: The submerged floating tunnel (SFT) was simplified as an elastically supported beam with uniform supporting spacings. The dynamics model was established to solve the vibration problem of the SFT under impact loads. With the Galerkin method, the timedisplacement responses at the central cross section of the SFT was numerically simulated. The influences of the anchor stiffness, the impact mass and the impact velocity on the SFT’s central displacement were analyzed. The present results indicate that the anchor stiffness has significant but bounded negative influence on the SFT’s central displacement. Moreover, the impact mass and the impact velocity have obvious positive effects on the SFT’s central displacement. The work provides a theoretical reference for further study and construction of the SFT.
- submerged floating tunnel /
- impact load /
- displacement response /
- parameter design /
- numerical simulation

HTML全文

参考文献(18)

[1]	Brancaleoni F, Castellani A, d’Asdia P. The response of submerged tunnels to their environment[J]. Engineering Structures,1989,1(11): 47-56.
[2]	Remseth S, Leira B J, Okstad K M, Mathisen K M, Hauks T. Dynamic response and fluid/structure interaction of submerged floating tunnels[J]. Computers and Structures,1999,4(72): 659-685.
[3]	LU Wei, GE Fei, WANG Lei, WU Xiao-dong, HONG You-shi. On the slack phenomena and snap force in tethers of submerged floating tunnels under wave conditions[J]. Marine Structures,2011,24(4): 358-376.
[4]	Sato M, Kanie S, Mikami T. Mathematical analogy of a beam on elastic supports as a beam on elastic fundation[J]. Applied Mathematical Modelling, 2008,32(5): 688-699.
[5]	Tariverdilo S, Mirzapour J, Shahmardani M, Shabani R, Gheyretmand C. Vibration of submerged floating tunnels due to moving loads[J]. Applied Mathematical Modelling,2011,35(11): 5413-5425.
[6]	田雪飞, 董满生, 逄焕平, 林志, 牛忠荣. 海洋内波和洋流联合作用下水中悬浮隧道的动力响应[J]. 应用数学和力学, 2014,35(1): 71-80.(TIAN Xue-fei, DONG Man-sheng, PANG Huan-ping, LIN Zhi, NIU Zhong-rong. The combined effect of ocean internal waves and currents of dynamic response in the tunnel water suspension[J]. Applied Mathematics and Mechanics,2014,35(1): 71-80.(in Chinese))
[7]	惠磊, 葛斐, 洪友士. 水中悬浮隧道在冲击荷载作用下的计算模型与数值模拟[J]. 工程力学, 2008,25(2): 209-213.(HUI Lei, GE Fei, HONG You-shi. Calculation model and numerical simulation of submerged floating tunnel subjected to impact loading[J]. Engineering Mechanics,2008,25(2): 209-213.(in Chinese))
[8]	任会兰, 宁建国. 冲击固体力学[M]. 北京: 国防工业出版社, 2013: 117.(REN Hui-lan, NING Jian-guo. Shock Dynamics of Solid [M]. Beijing: National Defense Industry Press, 2013: 117.(in Chinese))
[9]	刘福林. 简支弹塑性梁受冲击波作用时的动力响应的权余解法[J]. 机械强度, 1989,11(1): 48-52.(LIU Fu-lin. The weighted residual method of the dynamic response of simply supported elasto-plastic beams subjected to a impact loading[J]. Mechanical Strength,1989,11(1): 48-52.(in Chinese))
[10]	何勇, 金伟良, 张爱晖, 吴剑国. 船桥碰撞动力学过程的非线性数值模拟[J]. 浙江大学学报(工学版), 2008,42(6): 1065-1070.(HE Yong, JIN Wei-liang, ZHANG Ai-hui, WU Jian-guo. Nonlinear collision simulation on dynamic interaction between ship-bridge[J]. Journal of Zhejiang University(Engineering Science),2008,42(6): 1065-1070.(in Chinese))
[11]	项贻强, 晁春峰. 悬浮隧道管体及锚索耦合作用的涡激动力响应[J]. 浙江大学学报, 2012,46(3): 409-415.(XIANG Yi-qiang, CHAO Chun-feng. Vortex-induced dynamic response for combined action of tube and cable of submerged floating tunnel[J]. Journal of Zhejiang University,2012,46(3): 409-415.(in Chinese))
[12]	Srinil N, Zanganeh H. Modelling of coupled cross-flow/in-line vortex-induced vibrations using double Duffing and Van der Pol oscillators[J]. Ocean Engineering,2012,53: 83-97.
[13]	陈建云, 王变革, 孙胜男. 悬浮隧道锚索的涡激动力响应分析[J]. 工程力学, 2007,24(10): 186-192.(CHEN Jian-yun, WANG Bian-ge, SUN Sheng-nan. Analysis of vortex-induced dynamic response for the anchor cable of submerged floating tunnel[J]. Engineering Mechanics,2007,24(10): 186-192.(in Chinese))
[14]	麦继婷, 关宝树. 琼州海峡悬浮隧道的可行性研究[J]. 铁道工程学报, 2003(4): 93-96.(MAI Ji-ting, GUAN Bao-shu. A feasibility study on Qiongzhou strait submerged tunnel[J]. Journal of Railway Engineering Society,2003(4): 93-96.(in Chinese))
[15]	秦银刚, 周生国, 周晓军. 多跨悬浮隧道合理支撑间距分析[J]. 铁道工程学报, 2008,25(3): 78-81.(QIN Yin-gang, ZHOU Sheng-guo, ZHOU Xiao-jun. Analysis of the reasonable support length for multi-spans submerged floating tunnel[J]. Journal of Railway Engineering Society,2008,25(3): 78-81.(in Chinese))
[16]	JTG D60—2004, 公路桥涵设计通用规范[S].北京: 人民交通出版社, 2004.(JTG D60—2004, General specifications for design of highway bridges and culverts[S]. Beijing: China Communications Press, 2004.(in Chinese))
[17]	罗林阁, 曹映泓, 陈国虞, 王礼立. 船舶撞击桥梁的撞击力计算方法探讨[J]. 中外公路, 2006,26(5): 78-81.(LUO Lin-ge, CAO Ying-hong, CHEN Guo-yu, WANG Li-li. Discussion about the calculation method of ship-bridge model under impact[J]. Journal of China & Foreign Highway,2006,26(5): 78-81.(in Chinese))
[18]	JTG B02—2013, 公路工程抗震设计规范[S]. 北京: 人民交通出版社, 2013.(JTG B02—2013, Specification of seismic design for highway engineering[S]. Beijing: China Communications Press, 2013.(in Chinese))
