HUANG Zhitao, YANG Yu, SHAO Jiaru, ZHANG Yueyue. Numerical Simulation of SloshingMitigating Structures in Tank Trucks With the SPH Method[J]. Applied Mathematics and Mechanics, 2020, 41(7): 760-770. doi: 10.21656/1000-0887.400234
Citation: HUANG Zhitao, YANG Yu, SHAO Jiaru, ZHANG Yueyue. Numerical Simulation of SloshingMitigating Structures in Tank Trucks With the SPH Method[J]. Applied Mathematics and Mechanics, 2020, 41(7): 760-770. doi: 10.21656/1000-0887.400234

Numerical Simulation of SloshingMitigating Structures in Tank Trucks With the SPH Method

doi: 10.21656/1000-0887.400234
Funds:  The National Natural Science Foundation of China(11602045)
  • Received Date: 2019-08-03
  • Rev Recd Date: 2020-06-15
  • Publish Date: 2020-07-01
  • Based on the smooth particle hydrodynamics (SPH) method, the stability of the tank truck and the mitigating effects of different baffles were studied. Firstly, the liquid sloshing pressure in a rectangular container was simulated with results in agreement with experimental ones, to validate the effectiveness and accuracy of the SPH model. Secondly, a 2D elliptic tank truck model was established, which was filled with 93# gasoline. The impact pressure on the tank wall and the trajectory of the liquid barycenter were analyzed under different horizontal sinusoidal excitations and roll excitations. The results show that, the liquid sloshing is violent with no mitigating baffle, and the mitigating effects of the baffle will be influenced by the forms of external excitations. When the angle between the normal direction of the mitigating baffle and the inflow is small, the stability of the tank truck will be improved.
  • loading
  • [1]
    张海涛, 孙蓓蓓, 陈建栋. 基于自由液面预测的非线性液体晃动问题的数值模拟[J]. 东南大学学报(自然科学版), 2014,44(2): 277-282.(ZHANG Haitao, SUN Beibei, CHEN Jiandong. Numerical simulation of nonlinear liquid sloshing problems based on forecast of free surface[J]. Journal of Southeast University(Natural Science Edition),2014,44(2): 277-282.(in Chinese))
    赵树恩, 赵灵鹤. 汽车罐车横向运动液体晃动动力学特性模拟[J]. 应用数学和力学, 2014,35(11): 1259-1270.(ZHAO Shuen, ZHAO Linghe. Dynamic simulation of liquid sloshing characteristics for tank trucks in lateral movement[J]. Applied Mathematics and Mechanics,2014,35(11): 1259-1270.(in Chinese))
    FRANDSEN J B. Sloshing Motions in Excited Tanks [M]. Academic Press Professional, Inc, 2004.
    SOULI M, ZOLESIO J P. Arbitrary Lagrangian-Eulerian and free surface methods in fluid mechanics[J]. Computer Methods in Applied Mechanics and Engineering,2001,191(3/5): 451-466.
    LUCY L B. A numerical approach to the testing of the fission hypothesis[J]. The Astronomy Journal,1977,82(12): 1013-1024.
    〖JP2〗KOSHIZUKA S, OKA Y. Moving-particle semi-implicit method for fragmentation of incompressible fluid[J]. Nuclear Science and Engineering: the Journal of the American Nuclear Society,1996,123(3): 421-434.
    龚国毅. 基于VOF和浸入边界法的液舱晃荡的数值模拟[D]. 硕士学位论文. 广州: 华南理工大学,2013.(GONG Guoyi. Numerical simulation of tank sloshing based on volume of fluid and immersed boundary method[D]. Master Thesis. Guangzhou: South China University of Technology, 2013.(in Chinese))
    陈剑. 道路激励下罐式汽车液固耦合动力学性能研究[D]. 硕士学位论文. 南京: 东南大学, 2012.(CHEN Jian. The dynamics of liquid-structure interaction for tank vehicle subjected to road excitation[D]. Master Thesis. Nanjing: Southeast University, 2012.(in Chinese))
    张凯凯. 基于SPH方法的液舱内液体晃动分析及防晃研究[D]. 硕士学位论文. 哈尔滨: 哈尔滨工业大学, 2016.(ZHANG Kaikai. Analysis and research of the liquid sloshing and sloshing suppression in tanks based on SPH method[D]. Master Thesis. Harbin: Harbin Institute of Technology, 2016.(in Chinese))
    LIU G R, LIU M B. 光滑粒子流体动力学: 一种无网格粒子法[M]. 韩旭, 杨刚, 强洪夫, 译. 长沙: 湖南大学出版社, 2005.(LIU G R, LIU M B. Smooth Particle Hydrodynamics: a Meshless Particle Method [M]. HAN Xu, YANG Gang, QIANG Hongfu, transl. Changsha: Hunan University Press, 2005.(Chinese version))
    SHAO J R, LI H Q, LIU G R, et al. An improved SPH method for modeling liquid sloshing dynamics[J]. Computers & Structures, 2012,100/101: 18-26.
    刘谋斌, 周冉, 邵家儒. 棱形液舱内液体晃荡问题的SPH数值模拟[J]. 河海大学学报(自然科学版), 2014,42(3): 257-261.(LIU Moubin, ZHOU Ran, SHAO Jiaru. Numerical simulation of liquid sloshing in a prismatic tank with SPH method[J]. Journal of Hohai University (Natural Sciences),2014,42(3): 257-261.(in Chinese))
    TOUMI M, BOUAZARA M, RICHARD M J. Impact of liquid sloshing on the behaviour of vehicles carrying liquid cargo[J]. European Journal of Mechanics A: Solids,2009,28(5): 1026-1034.
    庄园, 万德成. FPSO船与低充水率下LNG液舱晃荡耦合运动的数值模拟[J]. 应用数学和力学, 2016,37(12): 1378-1393.(ZHUANG Yuan, WAN Decheng. Numerical study on coupling effects of FPSO ship motion and lng tank sloshing in low-filling conditions[J]. Applied Mathematics and Mechanics,2016,〖STHZ〗 37(12): 1378-1393.(in English))
    张友林, 陈翔, 万德成. 基于MPS-FEM耦合方法对比研究刚性与弹性挡板对液舱晃荡的抑制作用[J]. 应用数学和力学, 2016,37(12): 1359-1377.(ZHANG Youlin, CHEN Xiang, WAN Decheng. An MPS-FEM coupled method for the comparative study of liquid sloshing flows interacting with rigid and elastic baffles[J]. Applied Mathematics and Mechanics,2016,37(12): 1359-1377.(in English))
    LIU M B, SHAO J R, CHANG J Z. On the treatment of solid boundary in smoothed particle hydrodynamics[J]. Science China Technological Sciences,2012,55(1): 244-254.
    KISHEV Z R, HU C, KASHIWAGI M. Numerical simulation of violent sloshing by a CIP-based method[J]. Journal of Marine Science and Technology,2006,11: 111-122.
