LIU Jian-xin, LUO Ji-sheng. Effect of Disturbances at Inlet on Hypersonic Boundary Layer Transition on a Blunt Cone at Small Angle of Attack[J]. Applied Mathematics and Mechanics, 2010, 31(5): 505-515. doi: 10.3879/j.issn.1000-0887.2010.05.001
Citation: LIU Jian-xin, LUO Ji-sheng. Effect of Disturbances at Inlet on Hypersonic Boundary Layer Transition on a Blunt Cone at Small Angle of Attack[J]. Applied Mathematics and Mechanics, 2010, 31(5): 505-515. doi: 10.3879/j.issn.1000-0887.2010.05.001

Effect of Disturbances at Inlet on Hypersonic Boundary Layer Transition on a Blunt Cone at Small Angle of Attack

doi: 10.3879/j.issn.1000-0887.2010.05.001
  • Received Date: 2009-11-16
  • Rev Recd Date: 2010-03-25
  • Publish Date: 2010-05-15
  • Toinvestigate the effect of different disturbances in the up stream, we present numerical smiulation of transition for a hypersonic boundary layer on a 5-degree half-angle bluntcone in a freestream with Math number 6 at 1-degree angle of attack. Evolution of small disturbances is simulated to compare with linear stability theory(LST), indicating that LST can provide a good prediction on the growth rate of the disturbance. The effect of difference disturbances on transition was inves tigated. Transition on set distributions along the azmiuthal direction are obtained with two groups of disturbances of different frequencies. It shows that transition on set is relevant to the frequencies and amplitudes of the disturbances at the in let, and is decided by the amplitudes of themost unstable wave at the in let. According to the characters of the environmental disturbances in most wind tunnels, we explain why transition occurs leeside-forward and windside-aftovera circular coneatanangle of attack are explained. Moreover, the indentation phenom enon in transition curve on the leeward is also unpuzzled.
  • loading
  • [1]
    Fischer M C. An experimental investigation of boundary-layer transition on a 10-deg half-angle cone at Mach 6.9[R]. NASA-TN-D-5766, 1970.
    [2]
    Martellucci A, Neff R S, Truelll W H. An experimental investigation of boundary layer transition on a cone at angle of attack[R]. NASA TR-69-0383, 1969.
    [3]
    Muir J F, Trujillo A A. Experimental investigation of the effects of nose bluntness, free-stream unit Reynolds number, and angle of attack on cone boundary layer transition at a Mach number of 6[R]. AIAA Paper 72-0216, 1972.
    [4]
    Stetson K F, Thompson E R, Donaldson J C, et al. Laminar boundary layer stability experiments on a cone at Mach 8. Ⅰ—sharp cone[R]. AIAA Paper 83-1761, 1983.
    [5]
    Stetson K F, Thompson E R, Donaldson J C, et al. Laminar boundary layer stability experiments on a cone at Mach 8. Ⅲ—sharp cone at angle of attack[R]. AIAA Paper 85-0492, 1985.
    [6]
    Stetson K F, Thompson E R, Donaldson J C, et al. Laminar boundary layer stability experiments on a cone at Mach 8. Ⅳ—on unit Reynolds number and environmental effects[R]. AIAA Paper 86-1087, 1986.
    [7]
    Sakell L E. An experimental investigation of boundary Layer transition over three axially symmetric bodies at mach 6[D]. New York: New York University,School of Engineering and Science, 1972.
    [8]
    Schneider S P. Hypersonic laminar-turbulent transition on circular cones and scramjet forebodies[J]. Progress in Aerospace Sciences, 2004, 40(1/2): 1-50. doi: 10.1016/j.paerosci.2003.11.001
    [9]
    SU Cai-hong, ZHOU Heng. Transition prediction of a hypersonic boundary layer over a cone at small angle of attack with the improvement of eN- method[J]. Science in China Series, 2009, 52(1):115-123.
    [10]
    李新亮, 付德熏, 马延文. 超声速小攻角钝锥边界层转捩的直接数值模拟[J]. 气体物理理论与应用, 2009, 4(1):33-44.
    [11]
    Mack L M. Boundary-layer linear stability theory[R]. AGARD Report, 1984, No.709, 1984.
    [12]
    Balakumar P, Jeyasingham S. Evolution of disturbances in three-dimensional boundary layers[R]. AIAA-2000-0145, 2000.
    [13]
    董明, 罗纪生, 曹伟. 超音速尖锥边界层中扰动演化特征的数值研究[J]. 应用数学和力学, 2006, 27(6):631-636.
    [14]
    黄章峰, 周恒. 超音速边界层中二维扰动的演化及小激波的产生[J]. 应用数学和力学, 2004, 25(1):1-8. doi: 10.shtml
